Model | QM-630 | |
Dimension | 130*128*242mm | |
Net weight | 1.10kg | |
Printing direction | adjusted within 360 degree, meet all kinds of production needs | |
Character type | high-definition printing character, dot matrix font, Simplified, Traditional Chinese and English | |
Print Features | ||
Function | Handheld print and On line printing(Need Sensor extra) | |
Printing pictures | Pictures(BMP Monochrome single bitmap format)can be uploaded through USB disk | |
Printing accuracy | 300DPI 400DPI 600DPI | |
Printing height | 2mm-12.7mm | |
Print code | bar code, QR Code | |
Printing distance | 1-10mm Mechanical Adjustment (the best distance between the nozzle and printed object is 2-5mm) | |
Print serial number | 0~9 | |
Automatic print | date, time, batch number shift and serial number, etc | |
Storage | external USB save the information transfer in a free way | |
Message length | 2000 characters for each message, no limitation on length | |
Printing speed | 70m/min | |
Ink type | Quick-dry environmental ink, water-based ink and oily ink | |
Ink color | black, white, red, blue, yellow, green, invisible | |
Ink volume | 42ml(usually can print 800,000 characters) | |
Physical Features | ||
External interface | USB,Photoelectric interface, can directly insert a USB disk to upload information | |
Voltage | DC16.8V lithium battery, print continuously more than 10 hours and 20 hours standby | |
Control panel | touch-screen (can connect wireless mouse) | |
Power consumption | the average power consumption is lower than 5W | |
Working environment | Temperature:0 - 38 degree; Humidity: 10% - 80% | |
Printing material | board, carton, stone, pipe, cable, metal, plastic product, electronic, the fiber board, light steel keel, aluminum fo | |
